Module-Park Assist C1 (Standard) Connector End View (D3867A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 7283-9052-30

Part Description: YESC KAIZEN SUB- ASSEMBLY

Connector No: D3867A

Option: Standard

Repair Kit Part Number: 68080557AA

Cavity Count: 12

Fig 1: Module-Park Assist C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Park Assist C1 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Park Assist C1 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Park Assist C1 Component Location View (Standard)

Courtesy of CHRYSLER
