Module-Radio-Freq Hub C3 (Standard) Connector End View (D2665C)

Harness-Family: Antenna_Rem_St_RKE

Color: TAN

Gender: FEMALE

Part Number: 3FA1-NIRJ-C01-3

Part Description: Not Available

Connector No: D2665C

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Module-Radio-Freq Hub C3 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Radio-Freq Hub C3 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Radio-Freq Hub C3 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Radio-Freq Hub C3 Component Location View (Standard)

Courtesy of CHRYSLER
