Module-Door-Passenger C3 (Standard) Connector End View (D3819C)

Harness-Family: Door_Front_Pass

Color: NATURAL

Gender: FEMALE

Part Number: 2-2177196-1_2177231-1

Part Description: INNER HOUSING BLACK

Connector No: D3819C

Option: Standard

Repair Kit Part Number: 68156141AA

Cavity Count: 5

Fig 1: Module-Door-Passenger C3 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Door-Passenger C3 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Door-Passenger C3 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Door-Passenger C3 Component Location View (Standard)

Courtesy of CHRYSLER
