Guide Plate Pin
GUIDE PLATE PIN
INDEX
DEPTH
1. Pin
4mm (0.15in)
2. Guide Plate
-
Courtesy of CHRYSLER GROUP, LLC
Courtesy of CHRYSLER GROUP, LLC
