Module-Powertrain Control C1 (Standard) Connector End View (D3821A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 2035037-1_1924939-1

Part Description: GPEC II INSULATOR ASSEMBLY, RIGHT EXIT

Connector No: D3821A

Option: Standard

Repair Kit Part Number: 68148108AA

Cavity Count: 96

Fig 1: Module-Powertrain Control C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Powertrain Control C1 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Powertrain Control C1 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Powertrain Control C1 Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	N0	NA	0	NO CONNECT	N/A
2	N0	NA	0	NO CONNECT	N/A
3	N0	NA	0	NO CONNECT	N/A
4	N0	NA	0	NO CONNECT	N/A
5	N0	NA	0	NO CONNECT	N/A
6	N0	NA	0	NO CONNECT	N/A
7	N0	NA	0	NO CONNECT	N/A
8	N0	NA	0	NO CONNECT	N/A
9	N0	NA	0	NO CONNECT	N/A
10	N0	NA	0	NO CONNECT	N/A
11	N0	NA	0	NO CONNECT	N/A
12	N0	NA	0	NO CONNECT	N/A
13	N0	NA	0	NO CONNECT	N/A
14	N0	NA	0	NO CONNECT	N/A
15	N0	NA	0	NO CONNECT	N/A
16	N0	NA	0	NO CONNECT	N/A
17	N0	NA	0	NO CONNECT	N/A
18	N0	NA	0	NO CONNECT	N/A
19	N0	NA	0	NO CONNECT	N/A
20	N0	NA	0	NO CONNECT	N/A
21	N0	NA	0	NO CONNECT	N/A
22	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
22	K181	BN/YE	0.50	FUEL PRESSURE SIGNAL	6.2L
23	F942	PK/VT	0.35	FUSED IGNITION SWITCH OUTPUT (RUN-START)	N/A
24	X479	BN/DG	0.50	CRANKSHAFT PULSE SIGNAL (-)	N/A
25	N0	NA	0	NO CONNECT	N/A
26	N0	NA	0	NO CONNECT	N/A
27	N0	NA	0	NO CONNECT	N/A
28	N0	NA	0	NO CONNECT	N/A
29	X478	BN/GN	0.50	CRANKSHAFT PULSE SIGNAL (+)	N/A
30	N0	NA	0	NO CONNECT	N/A
31	N0	NA	0	NO CONNECT	N/A
32	N0	NA	0	NO CONNECT	N/A
33	D28	YE	0.35	CAN C (-)	N/A
34	N0	NA	0	NO CONNECT	N/A
35	N0	NA	0	NO CONNECT	N/A
36	N0	NA	0	NO CONNECT	N/A
37	N0	NA	0	NO CONNECT	N/A
38	N0	NA	0	NO CONNECT	N/A
39	N0	NA	0	NO CONNECT	N/A
40	N0	NA	0	NO CONNECT	N/A
41	N0	NA	0	NO CONNECT	N/A
42	K914	BN/WH	0.50	SENSOR GROUND	N/A
43	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
43	K222	BN/YE	0.50	ECT 2 SIGNAL	6.2L
44	C18	BU/BN	0.35	A/C PRESSURE SIGNAL	N/A
45	N0	NA	0	NO CONNECT	N/A
46	K806	DB/BN	0.75	STOP START HOOD AJAR SW SIG	3.0L GAS 3.6L
46	N0	NA	0	NO CONNECT	5.7L 6.2L 6.4L
47	N0	NA	0	NO CONNECT	N/A
48	N8	DB/PK	0.50	FUEL TANK PRESSURE SENSOR SUPPLY	N/A
49	N0	NA	0	NO CONNECT	N/A
50	N0	NA	0	NO CONNECT	N/A
51	N0	NA	0	NO CONNECT	N/A
52	Z909	BK	1.5	GROUND	N/A
53	Z909	BK	1.5	GROUND	N/A
54	N10	DB/WH	0.50	FUEL TANK PRESSURE SENSOR RETURN	N/A
55	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
55	D511	WH/BG	0.75	LIN BUS	6.2L
56	N0	NA	0	NO CONNECT	N/A
57	D27	BG/WH	0.35	CAN C (+)	N/A
58	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
58	K46	DB/BU	0.50	BANK 1 TEMP SIGNAL	6.2L
59	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
59	K47	DB/YE	0.50	BANK 2 TEMP SIGNAL	6.2L
60	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
60	K49	VT/BU	0.50	ENGINE CHARGE AIR TEMPERATURE OUT SIGNAL	6.2L
61	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
61	N12	DB/GN	0.50	FPCM PWM FEEDBACK	6.2L
62	N0	NA	0	NO CONNECT	N/A
63	N0	NA	0	NO CONNECT	N/A
64	N0	NA	0	NO CONNECT	N/A
65	N0	NA	0	NO CONNECT	N/A
66	N0	NA	0	NO CONNECT	N/A
67	K400	BN/VT	0.50	APP SENSOR GROUND 2	N/A
68	K167	BN/YE	0.50	APP SENSOR GROUND 1	N/A
69	K854	VT/BN	0.50	5 VOLT SUPPLY	N/A
70	K108	VT/GY	0.50	ESIM SIGNAL	N/A
71	N0	NA	0	NO CONNECT	N/A
72	Z909	BK	1.5	GROUND	N/A
73	N9	DB	0.50	FUEL PUMP RELAY CONTROL	N/A
74	F342	BN/WH	1.5	ASD RELAY OUTPUT	N/A
75	F342	BN/WH	1.5	ASD RELAY OUTPUT	N/A
76	F342	BN/WH	1.5	ASD RELAY OUTPUT	N/A
77	T110	DG/YE	0.50	VACUUM PUMP RELAY CONTROL	3.0L GAS 3.6L
77	N0	NA	0	NO CONNECT	5.7L 6.2L 6.4L
78	N112	DB/OG	0.50	RAD FAN RELAY CONTROL	3.0L GAS 3.6L
78	N0	NA	0	NO CONNECT	5.7L 6.2L 6.4L
79	C13	BU/OG	0.35	A/C CLUTCH CONTROL	N/A
80	K51	BN/WH	0.75	ASD RELAY CONTROL	N/A
81	T752	DG/OG	0.50	STARTER RELAY CONTROL	N/A
82	K175	BN/BU	0.50	RAD FAN CONTROL	HEAVY DUTY COOLING
82	N201	DB/GN	0.50	LOW SPEED RAD FAN CONTROL	STANDARD DUTY COOLING
83	N0	NA	0	NO CONNECT	3.0L GAS 3.6L 5.7L 6.4L
83	N11	DB/BG	0.50	FPCM PWM CONTROL	6.2L
84	N0	NA	0	NO CONNECT	N/A
85	N0	NA	0	NO CONNECT	N/A
86	N0	NA	0	NO CONNECT	N/A
87	N0	NA	0	NO CONNECT	N/A
88	N7	DB/OG	0.50	FUEL TANK PRESSURE SIGNAL	N/A
89	N0	NA	0	NO CONNECT	N/A
90	N0	NA	0	NO CONNECT	N/A
91	K29	WH/BN	0.50	APP SIGNAL 2	N/A
92	K23	BN/WH	0.50	APP SIGNAL 1	N/A
93	K852	GY/BU	0.50	5 VOLT SUPPLY	N/A
94	K52	DB/WH	0.50	EVAP PURGE CONTROL	N/A
95	K501	BN	0.50	COOLANT BYPASS VALVE CONTROL	3.0L GAS 3.6L
95	N0	NA	0	NO CONNECT	5.7L 6.2L 6.4L
96	A209	RD	1.5	FUSED B(+)	N/A
