Module-Central Vision Processing C1 (Standard) Connector End View (D2999A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 2065230121

Part Description: Not Available

Connector No: D2999A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Central Vision Processing C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Central Vision Processing C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F931

PK/YE

0.35

FUSED IGNITION RUN CONTROL OUTPUT

N/A

D329

WH/GY

0.35

CAN IHS (+)

N/A

D332

0.35

CAN IHS (-)

N/A

Z925

BK/VT

0.35

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
