Ignition Lock Switch

Remove the ignition lock switch and check continuity between the terminals as illustrated. See Fig 1. If the continuity is not as specified, replace the switch.

Fig 1: Checking Ignition Lock Switch

Courtesy of KIA MOTORS AMERICA, INC.
