Component Inspection

WARNING: This page is about a different car, the 2007 Kia Sedona and 2006 Kia Sedona. However, it is still accessible from the selected car via links, so may be relevant.

Ignition "OFF".
Remove "TRANSAXLE RANGE SWITCH".
Measure the resistance between each terminal of the sensor.
Specification: approx. 0 Ω

Fig 1: Measuring Resistance Between Each Terminal Of Sensor
Courtesy of KIA MOTORS AMERICA, INC.
Is resistance within specifications?
YES
- Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.
NO
- Replace "TRANSAXLE RANGE SWITCH" as necessary and Go to "VERIFICATION OF VEHICLE REPAIR " procedure.
