Rio Base, Automatic
>>
Repair and Diagnosis
>>
Engine Performance
>>
System
>>
DTC Troubleshooting Procedures (1 Of 2)
>>
DTC P0030 Ho2S Heater Control Circuit (Bank 1/Sensor 1)
>>
Schematic Diagram
>>
(A/T)
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Schematic Diagram: (A/T)
Fig 1: A/T Schematic Diagram
Courtesy of KIA MOTORS AMERICA, INC.
