Tightening Torques
| Item | N.m | kgf.m | lb-ft |
|---|---|---|---|
| Ignition coil bolt | 9.8 ~ 11.8 | 1.0 ~ 1.2 | 7.2 ~ 8.7 |
| Spark plug | 14.7 ~ 24.5 | 1.5 ~ 2.5 | 10.8 ~ 18.1 |
| Condenser bolt | 9.8 ~ 11.8 | 1.0 ~ 1.2 | 7.2 ~ 8.7 |
| Alternator B-terminal cable nut | 9.8 ~ 14.7 | 1.0 ~ 1.5 | 7.2 ~ 10.8 |
| Alternator mounting bolt (M10) | 29.4 ~ 41.2 | 3.0 ~ 4.2 | 21.7 ~ 30.4 |
| Alternator mounting bolt (M8) | 21.6 ~ 32.4 | 2.2 ~ 3.3 | 15.9 ~ 23.9 |
| Alternator brace mounting bolt | 21.6 ~ 32.4 | 2.2 ~ 3.3 | 15.9 ~ 23.9 |
| Battery positive terminal | 7.8 ~ 9.8 | 0.8 ~ 1.0 | 5.8 ~ 7.2 |
| Battery negative terminal | 3.9 ~ 5.9 | 0.4 ~ 0.6 | 3.0 ~ 4.4 |
| ECM & bracket bolt | 19.6 ~ 29.4 | 2.0 ~ 3.0 | 14.5 ~ 21.7 |
| ECM & bracket nut | 7.8 ~ 11.8 | 0.8 ~ 1.2 | 5.8 ~ 8.7 |
| Battery tray mounting bolt | 8.8 ~ 13.7 | 0.9 ~ 1.4 | 6.5 ~ 10.1 |
| Starter B-terminal cable nut | 9.8 ~ 11.8 | 1.0 ~ 1.2 | 7.2 ~ 8.7 |
| Starter mounting bolt | 42.2 ~ 53.9 | 4.3 ~ 5.5 | 31.1 ~ 39.8 |
CAUTION:
- COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature.
- RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C(80.1°F).
