Repair Procedures: Removal

  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the floor mat in the trunk.
  3. Remove the service cover (A).
    Fig 1: Identifying Service Cover
    G09751321Courtesy of KIA MOTORS AMERICA, INC.
  4. Disconnect the fuel tank pressure sensor connector.
  5. Remove the fuel tank pressure sensor (A) after releasing the hooks vertically.
    Fig 2: Identifying Fuel Tank Pressure Sensor
    G09751322Courtesy of KIA MOTORS AMERICA, INC.
