Repair Procedures: Replacement

Remove the under cover.
(Refer to "ENGINE ROOM UNDER COVER ".
Remove the drain plug (A) and drain the ATF totally and then reinstall the drain plug.
NOTE: Must be replaced with new gasket when installing the drain plug.

Drain plug tightening torque:

33.3 ~ 43.1 N.m (3.4 ~ 4.4 kgf.m, 24.6 ~ 31.8 lb-ft)

Fig 1: Identifying Drain Plug
Courtesy of KIA MOTORS AMERICA, INC.
Remove the air cleaner assembly.
(Refer to "AIR CLEANER ")
Remove the eyebolt (A).
Tightening torque:

2.9 ~ 4.9 N.m (0.3 ~ 0.5 kgf.m, 2.2 ~ 3.6 lb-ft)

Fig 2: Identifying Eyebolt (A)
Courtesy of KIA MOTORS AMERICA, INC.
Fill the fluid about 5 liters through injection hole.
Perform the fluid level check.
(Refer to appropriate Hydraulic System article .
