Terminal and Connector Inspection

1. Many malfunctions in the electrical system are caused by poor harness and terminals.

   Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.

2. Thoroughly check connectors for backed out terminal, improper mating, broken locks, looseness, poor connection, bending, corrosion, contamination, deterioration, damage or poor terminal to wire connection.
3. Has a problem been found?

Courtesy of KIA MOTORS AMERICA, INC.

YES

• Repair as necessary and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.

NO

• Go to "Ground Circuit Inspection " procedure.
