Component Inspection

Check APS

1. Connect KDS/GDS to DLC (Data Link Cable).
2. Warm up the engine to normal operating temperature.
3. Check the "Current Data" about related DTC with KDS/GDS.
   Fig 1: Screen Display - Engine Idle After Warm Up & Approx. 2000RPM & At Acceleration

   Courtesy of KIA MOTORS AMERICA, INC.
4. Are the parameters displayed correctly?

   YES

   • Go to "Verification Of Repair " procedure.

   NO

   • Carefully re-do this troubleshooting guide steps.
   • If problem still occurs, replace APS and then go to "Verification Of Repair " procedure.
