Idle Stop & Go (ISG) System - 2.0L: AGM-Battery: Specifications

AGM80L-DIN

Information

• Model type description

  Courtesy of KIA MOTORS AMERICA, INC.

• Cold Cranking Ampere (CCA): A rating used in the battery industry to define a battery's ability to start an engine in cold temperatures.

• The rating is the number of amps a new, fully charged battery can deliver at -18 °C(-0.4 °F) for 30 seconds, while maintaining a voltage of at least 7.2 volts for a 12 volt battery.
• The higher the CCA rating, the greater the starting power of the battery.

• RESERVE CAPACITY (RC): A battery industry rating, defining a battery's ability to power a vehicle with an inoperative alternator or fan belt.
  • The rating is the number of minutes a battery at 26.7 °C(80 °F) can be discharged at 25 amps and maintain a voltage of 10.5 volts for a 12 volt battery.
  • The higher the reserve rating, the longer your vehicle can operate should your alternator or fan belt fail.

  Information

  BCI Type

  Capacity (5HR/20HR)	Length	Width	Height	Total Height
  	L (mm)	W (mm)	T (mm)	TH (mm)
  28/35	188 - 192	126 - 130	198 - 202	218 - 222
  32/40	194 - 198	133 - 137	199 - 203	223 - 227
  36/45	203 - 207	173 - 177	200 - 204	221 - 225
  44/55	213 - 217	173 - 177	198 - 202	218 - 222
  48/60	228 - 232	173 - 177	200 - 204	221 - 225
  54/68	258 - 262	173 - 177	198 - 202	220 - 224
  56/70	258 - 262	173 - 177	198 - 202	223 - 227
  64/80	274 - 278	170 - 174	198 - 202	221 - 225
  70/88	349 - 353	172 - 176	186 - 200	183 - 187
  72/90	300 - 304	170 - 174	200 - 204	221 - 225
  76/95	294 - 298	172 - 176	198 - 202	220 - 224
  80/100	326 - 330	170 - 174	203 - 207	225 - 229

Courtesy of KIA MOTORS AMERICA, INC.

DIN Type

AGM DIN Type

Courtesy of KIA MOTORS AMERICA, INC.
