TCM adaptive values learning procedure

  1. Drive the vehicle through all the gears. (1st → 2nd → 3rd → 4th → 5th → 6th)
    NOTE: Keep the throttle position (15 - 25%) steady while driving the vehicle.
  2. Decelerate the vehicle by stepping on the brake (6th → 5th → 4th → 3rd → 2nd → 1st).
  3. Repeat the above procedure four times.
