Engine Room Relay Block Assembly No. 2 (M20A-FXS) Inner Circuit

Fig 1: Engine Room R/B And J/B Assembly No. 2 (M20A-FXS) Circuit Diagram (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

ENGINE ROOM R/B AND J/B No. 2 (M20A-FXS) INNER CIRCUIT RELAY IDENTIFICATION

Fig 2: Engine Room R/B And J/B Assembly No. 2 (M20A-FXS) Circuit Diagram (2 Of 2)

ENGINE ROOM R/B AND J/B No. 2 (M20A-FXS) INNER CIRCUIT RELAY IDENTIFICATION

RELAY DESCRIPTION
WIPER Relay
H-LP SHADE Relay
