Operation Check [10/2016 - 09/2020]

  1. CHECK PRE-COLLISION SYSTEM SETTING
    1. Turn the engine switch on (IG).
    2. Operate the steering pad switch assembly to change the setting of PCS on the multi-information display to "On" and check that the pre-collision system turns on.

      HINT:

      When the engine switch is turned on (IG), the PCS will turn on. This can be changed through a customize setting using the Techstream.

    3. Operate the steering pad switch assembly to change the PCS setting to "Off" and check that the PCS warning light illuminates.
      GTY535348Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      *a PCS Warning Light
  2. CHECK PRE-COLLISION SYSTEM SENSITIVITY SETTING
    1. Turn the engine switch on (IG).
    2. Operate the steering pad switch assembly to select Change PCS Sensitivity and check that the warning timing adjustment display on the multi-information display changes between "Far", "Mid" and "Near" accordingly.

      HINT:

      • The pre-collision system warning timing status remains unchanged when the engine switch is turned off and back to ON. This can be changed through a customize setting using the Techstream.
      • The default setting is "Mid".
