DTC B22D4: Sub Battery Module Protection Relay Temperature Sensor Circuit [12/2017 - 10/2023]: Wiring Diagram

GTY822765Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*a Sub-battery Module Assembly - -
*1 Protection relay temperature sensor *2 Temperature detection circuit
*3 CPU - -
