Steering Column: Specification
Torque Specifications (1 Of 2)
| Description | Nm | Lb-Ft | Lb-In |
|---|---|---|---|
| Steering wheel retaining bolt | 31 - 48 | 23 - 25 | - |
| Clockspring screw | 2 - 3 | - | 18 - 26 |
| Steering column mounting nut | 13 - 17 | 10 - 12 | - |
| Steering column upper and lower yoke bolts | 25 - 35 | 19 - 25 | - |
| Steering actuator housing pivot bolt | 18 - 26 | 14 - 19 | - |
| Ignition switch bolt | 5.3 - 7.2 | - | 47 - 64 |
| Shift selector tube screws | 7 - 11 | - | 62 - 97 |
| Driver air bag module nuts | 4 - 5 | - | 36 - 44 |
Torque Specifications (2 Of 2)
| Description | Nm | Lb-Ft | Lb-In |
|---|---|---|---|
| Steering column lower bearing retainer screws | 7 - 11 | - | 62 - 97 |
| Steering column boot nut | 5 - 6 | - | 45 - 53 |
| Multi-function switch screws | 2 - 3 | - | 18 - 26 |
| Steering column impact absorber | 13 - 19 | 10 - 14 | - |
| Steering column trim shroud screws | 0.6 - 1.0 | - | 6 - 8 |
| Shift cable and bracket-to-column screws | 7 - 11 | - | 62 - 97 |
| Shift lock actuator | 2 - 3 | - | 18 - 26 |
| Knee bolster | 13 - 17 | 10 - 12 | - |
| Instrument panel reinforcement brace | 13 - 17 | 10 - 12 | - |
| Brace release lever | 2 - 3 | - | 18 - 26 |
| Hood release lever | 2 - 3 | - | 18 - 26 |
| Lower instrument panel trim cover | 2 - 3 | - | 18 - 26 |
| Transmission selector lever arm and support | 12.7 - 17.2 | 10 - 13 | - |
