Generator - 3.9L: Notes

CAUTION: The generator must be supported by hand after removing the bolts prior to disconnecting the electrical connector or damage to the harness may result.

CAUTION: Care must be taken when removing the generator to prevent damage to the air conditioning and cooling lines.

NOTE: The A/C suction line may need to be positioned rearward to ease removal of the generator.

Disconnect the battery. For additional information, Refer to BATTERY DISCONNECT .
Position the front end accessory drive belt aside.
Remove the front valance panel end air deflector.
Remove the components, in the order indicated in Fig 1.

Fig 1: Removing Sequence Of Generator - 3.9L
Courtesy of FORD MOTOR CO.
To install, reverse the removal procedure.
