System Specifications

Timing Chain Tensioner Bolts 25 Nm (18 lb-ft).

Crankshaft Pulley Bolt
Step 1 120 Nm (89 lb-ft).
Step 2 Loosen bolt one full turn
Step 3 50 Nm (37 lb-ft).
Step 4 Tighten an additional 90°

Engine Front Cover Front Fasteners 25 Nm (18 lb-ft).











Engine Front Cover Lower Fasteners
Stage 1 20 Nm (15 lb-ft).
Stage 2 Tighten an additional 90°
