System Specifications

Timing Chain Tensioner Bolts

Tighten to 25 Nm (18 lb-ft).

Crankshaft Pulley Torque

Install the bolt and washer and tighten the crankshaft pulley bolt in 4 stages.
Stage 1: Tighten to 120 Nm (89 lb-ft).
Stage 2: Loosen 360 degrees.
Stage 3: Tighten to 50 Nm (37 lb-ft).
Stage 4: Rotate an additional 90 degrees (one-fourth turn).

Timing Cover(Engine Front Cover)

Tighten the front cover fasteners in the sequence shown to 25 Nm (18 lb-ft).
