Right-Rear Wheel Speed Sensor

Fig 1: Locating Right-Rear Wheel Sensor, Retainer And Bolts
G07929144Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W500010 Wheel speed sensor bolt
2 2C190 Wheel speed sensor
