Frame Components

Fig 1: Identifying Frame Mounted Heat Shields Components

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	-	Body-to-frame mounts
2	-	Front crossmember No. 1
3	-	1B crossmember
4	-	RH frame rail
5	-	Transmission crossmember
6	-	Crossmember No. 3
7	-	Crossmember No. 4
8	-	Crossmember No. 5
9	-	Crossmember No. 6
10	-	LH frame rail
11	-	Tow hook bolt (4 required)
12	-	Tow hook (2 required)
13	-	Tow hook nut plate (2 required)
