Pinpoint Test Ta: Clutch Pedal Position (CPP) Switch: Introduction

This pinpoint test is intended to diagnose the following:

Fig 1: Clutch Pedal Position (CPP) Switch Connector

Courtesy of FORD MOTOR CO.

Harness Side

Circuit	Pin
CPP-BT (Clutch Pedal Position - Bottom of Travel)	1
GND (Ground)	2

Fig 2: Powertrain Control Module (PCM) Connector - For PCM Connector Views

Courtesy of FORD MOTOR CO.

Harness Side

Circuit	Pin
CPP-BT (Clutch Pedal Position - Bottom of Travel)	B7
