Trouble Code Access

Using jumper wire, ground Green 1-pin connector. Connector is located at left front wheelwell. See Figure .

Fig 1: Green 1-Pin Test Connector
Courtesy of MAZDA MOTORS CORP.
With ignition on and engine stopped, observe "CHECK ENGINE" or MIL light. Note trouble codes. Check TROUBLE CODE IDENTIFICATION chart for possible cause. If light remains on continuously, MIL circuit is grounded or ECU is defective.
