System Tests: Tribute: Notes
SYMPTOM INDEX (TRIBUTE)
| Symptom | Test |
|---|---|
| Charging System Warning Indicator Is ON With Engine Running (3.0L) | A |
| Charging Warning Indicator is ON With Engine Running (2.0L) | B |
| Charging System Overcharges Battery (3.0L) | C |
| Charging System Overcharges Battery (2.0L) | D |
| Charging System Warning Indicator Is ON & Engine Is Running (3.0L) | E |
| Charging System Warning Indicator Is ON & Engine Is Running | F |
| Charging System Warning Indicator Is OFF & Ignition Switch Is In RUN Position With Engine OFF. (3.0L) | G |
| Charging System Warning Indicator Is ON & Ignition Switch In RUN Position With Engine OFF. (2.0L) | H |
| Charging System Warning Indicator Flickers (3.0L) | I |
| Charging System Warning Indicator Flickers (2.0L) | J |
| Generator Is Noisy | K |
| Radio Interference | L |
