The Remote Transmitter Has Poor Range Performance

NOTE:

• All remote transmitters must be present to begin diagnosis of the remote keyless entry (RKE) system.

NOTE:

• Aftermarket or dealer-installed systems may adversely affect the RKE system operation. These systems should be disconnected before diagnosing any RKE concerns.

Fig 1: Pinpoint Test 7: Remote Transmitter Poor Range Performance Inspection Table (Steps 1-4)

Courtesy of MAZDA MOTORS CORP.
