Timing Cover

Timing Cover

Position the engine front cover and install the 5 bolts and 5 stud bolts.






Tightening Torque 19 Nm {1.9 kgf-m, 14 ft-lbf}

Install the 5 cylinder block cradle-to-front cover bolts.

The 5 bolts may or may not have washers. All the bolts should be of the same type.

Tightening Torque With washers: 10 Nm {1.0 kgf-m, 89 in-lbf}
Without washers: 14 Nm {1.4 kgf-m, 10 ft-lbf}
