Keyless Beeper Removal/Installation - With Advanced Keyless Entry and Start System




KEYLESS BEEPER REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND START SYSTEM]

1. Disconnect the negative battery cable.

2. Remove the rear bumper. Removal and Replacement

3. Remove the nuts.

4. Disconnect the connector, then remove the keyless antenna.






5. Install in the reverse order of removal.
