Rear Wheel Alignment





REAR WHEEL ALIGNMENT

Rear wheel alignment (unloaded)*1





*1
Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
*2
Difference between left and right must not exceed 1°30'.
