Clip Removal Note

Pull out the pin with flathead screwdriver as shown in the figure.

Fig 1: Pulling Out Pin Using Flathead Screwdriver
Courtesy of MAZDA MOTORS CORP.
Insert a flathead screwdriver into shown in the figure.

Fig 2: Inserting Flathead Screwdriver Into Air Bag System Warning Light
Courtesy of MAZDA MOTORS CORP.
While pulling the curtain air bag in the direction of the arrow shown in the figure (1), detach tabs by prying with a flathead screwdriver in the direction of the arrow (2) (3).

Fig 3: Pulling Curtain Air Bag Tabs
Courtesy of MAZDA MOTORS CORP.
Remove the clip from the body.
