Troubleshooting Procedure

Fig 1: SAS Control Module Troubleshooting Flowchart (Standard Deployment Control System)
G11438746Courtesy of MAZDA MOTORS CORP.

*1: CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW.
