Troubleshooting Procedure

Fig 1: SAS Control Module (Two-Step Deployment Control System) Troubleshooting Chart
G09075957Courtesy of MAZDA MOTORS CORP.

*1 CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [SKYACTIV-G 2.5], CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [SKYACTIV-G 2.5T].
