DTC B1417-11/B1417-13/B1417-87/B1417-96: Passenger-Side Crash Zone Sensor Circuit [SAS Control Module (Two-Step Deployment Control System)]: Notes

DTC B1417:11/B1417:13/B1417:87/B1417:96 - SAS CONTROL MODULE (TWO-STEP DEPLOYMENT CONTROL SYSTEM) DETECTION CONDITION AND POSSIBLE CAUSE

System malfunction location	B1417:11: Passenger-side crash zone sensor circuit short to body ground B1417:13: Passenger-side crash zone sensor circuit open circuit or short to power supply B1417:87: Signal reception error from passenger-side crash zone sensor B1417:96: Passenger-side crash zone sensor internal malfunction
Detection condition	WARNING: Detection conditions are for understanding the DTC outline before performing an inspection. Performing an inspection according to only the detection conditions may cause injury due to an operating error, or damage the system. When performing an inspection, always follow the inspection procedure. Wiring harness between the passenger-side crash zone sensor and SAS control module has a malfunction Passenger-side crash zone sensor has a malfunction
Fail-safe	Not applicable
Possible cause	Passenger-side crash zone sensor connector malfunction Short circuit to power supply or body ground in the wiring harness between the passenger-side crash zone sensor and SAS control module Open circuit in the wiring harness between the passenger-side crash zone sensor and SAS control module Short circuit to power supply or body ground in wiring harness between the driver-side side air bag sensor No. 2 and SAS control module Passenger-side crash zone sensor malfunction SAS control module malfunction

Courtesy of MAZDA MOTORS CORP.
