DTC B1DA0-79: Exceeds Maximum Number Of Pulse Counts For Top Lock Motor [Retractable Hardtop Control Module]: Notes

DTC B1DA0:79 (RETRACTABLE HARDTOP CONTROL MODULE) DETECTION CONDITION AND POSSIBLE CAUSE

Description	Exceeds maximum number of pulse counts for top lock motor
Detection condition	The retractable hardtop control module detects a pulse signal exceeding the maximum number of the pulse counts from the top lock motor.
Fail-safe	Stops retractable hardtop operation
Possible cause	Poor top lock motor installation Top lock motor malfunction Retractable hardtop control module malfunction
Courtesy of MAZDA MOTORS CORP.
