DTC P025C-00: Fuel Pump Control Module System: Result Of On-Board Diagnostic Test Low Input
WARNING: This page is about a different variant/trim than selected.
P025C-00: (PCM - VIN Y) DETECTION CONDITION AND POSSIBLE CAUSE
| System malfunction location |
Fuel pump control module system: Result of on-board diagnostic test low input |
| Detection condition |
- Result of on-board test cannot be received from fuel pump control module (voltage is too low).
|
| Fail-safe |
|
| Possible cause |
- Malfunction in wiring harness (including connector/terminal) between fuel pump control module and PCM (see CIRCUIT INSPECTION
.) (see CLEARING DTC
.)
- Fuel pump control module malfunction (Refer to applicable FUEL PUMP CONTROL MODULE INSPECTION (VIN Y)
in the service information.)
- PCM malfunction (Refer to applicable PCM REMOVAL/INSTALLATION (VIN Y)
in the service information.)
|
| Repeatability verification procedure |
- Clear the DTC recorded in the memory. (see CLEARING DTC
.)
- Perform the KOEO or KOER self test. (See DTC INSPECTION
.)
|
 Courtesy of MAZDA MOTORS CORP.
|
| 1 |
PCM |
| 2 |
Fuel pump control module |
