DTC P1A0D-00: Drive Motor Control Module: Signal Error
P1A0D: 00 (SGC2/DMCM (WITH MAZDA M HYBRID BOOST)) DETECTION CONDITION AND POSSIBLE CAUSE
| System malfunction location |
Drive motor control module: Signal error |
| Detection condition |
- The drive motor control module receives a crash detection low voltage signal from the PCM.
|
| Fail-safe |
|
| Possible cause |
- Malfunction in wiring harness (including connector/terminal) between PCM and drive motor control module (See CIRCUIT INSPECTION
.) (See CONNECTOR INSPECTION
.)
- PCM malfunction (Refer to [PCM REMOVAL/INSTALLATION
] in service information).
- Drive motor control module malfunction (Refer to [INVERTER REMOVAL/INSTALLATION
] in service information).
|
| Repeatability verification procedure |
- Clear the DTC recorded in the memory. (See CLEARING DTC
.)
|
 Courtesy of MAZDA MOTORS CORP.
|
| 1 |
PCM |
| 2 |
Drive motor control module |
