Troubleshooting Procedure

WARNING: This page is about a different car, the 2016 Mazda MX-5 Miata. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: SAS Control Module Troubleshooting Procedure Flowchart
G10953332Courtesy of MAZDA MOTORS CORP.
