| A0 |
Color code key |
88L |
| B29/4 |
Left rear bumper intelligent radar sensor |
53L |
| B29/4 |
Left rear bumper intelligent radar sensor |
53L |
| B29/5 |
Right rear bumper intelligent radar sensor |
54L |
| B29/5 |
Right rear bumper intelligent radar sensor |
54L |
| CAN B |
Interior CAN |
19K |
| CAN B |
Interior CAN |
26K |
| Code 234 |
Blind spot assist |
51G |
| Code 234 |
Blind spot assist |
52G |
| Code 238 |
Active Lane Keeping Assist |
32G |
| Code 23P |
Driver assistance package PLUS |
47G |
| Code 23P |
Driver assistance package PLUS |
47G |
| Code 275 |
Memory package, electrically adjustable front seats |
35G |
| Code 275 |
Memory package, electrically adjustable front seats |
43G |
| Code 409 |
Left and right front multicontour seats |
11G |
| Code 432 |
Left and right front dynamic multicontour seats |
14G |
| Code 432 |
Left and right front dynamic multicontour seats |
21G |
| Code 443 |
Steering wheel heater |
28G |
| Code 443 |
Steering wheel heater |
32G |
| Code 476 |
Automatic lane detection |
32G |
| Code 494 |
USA version |
77A |
| Code 494 |
USA version |
79G |
| Code 4U7 |
Start/stop voltage dip protection |
1H |
| Code 550 |
Trailer hitch |
67G |
| Code 631 |
A11-LED headlamps (without ILS), daytime running lamps integrated in |
79G |
| |
headlamp, for left-hand traffic |
|
| Code 632 |
A11-LED headlamps (without ILS), daytime running lamps integrated in |
79H |
| |
headlamp, for right-hand traffic |
|
| Code 640 |
All-LED USA incl. ACTIVE MULTIBEAM LED |
79G |
| Code 872 |
Left and right rear seat heaters |
39G |
| Code 881 |
Trunk lid/liftgate control |
56G |
| Code B03 |
ECO start/stop function |
1G |
| Code U42 |
BlueTEC diesel exhaust treatment |
8G |
| Code U77 |
BLUETEC (SCR) diesel exhaust treatment |
8G |
| E1 |
Left front lamp unit |
83K |
| E2 |
Right front lamp unit |
84K |
| F32 |
Front electrical prefuse box |
4L |
| F32f158 |
Prefuse 158 |
2K |
| F32f159 |
Prefuse 159 |
6K |
| F32f163 |
Prefuse 163 |
2K |
| F32f164 |
Prefuse 164 |
6K |
| M40 |
Multicontour seat pneumatic pump |
13L |
| M40/1 |
Active multicontour seat pneumatic pump |
16L |
| M40/1 |
Active multicontour seat pneumatic pump |
23L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
4A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
12A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
28A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
20A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
36A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
53A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
60A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
76A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
43A |
| N10/2f53 |
Fuse 53 |
74A |
| N10/2f54 |
Fuse 54 |
73A |
| N10/2f55 |
Fuse 55 |
67A |
| N10/2f56 |
Fuse 56 |
68A |
| N10/2f57 |
Fuse 57 |
71A |
| N10/2f58 |
Fuse 58 |
69A |
| N10/2f59 |
Fuse 59 |
52A |
| N10/2f60 |
Fuse 60 |
17A |
| N10/2f61 |
Fuse 61 |
59A |
| N10/2f62 |
Fuse 62 |
44A |
| N10/2f63 |
Fuse 63 |
41A |
| N10/2f64 |
Fuse 64 |
37A |
| N10/2f65 |
Fuse 65 |
31A |
| N10/2f89 |
Fuse 89 |
79A |
| N10/2f90 |
Fuse 90 |
9A |
| N10/2kA |
Circuit 15 relay |
56A |
| N118 |
Fuel pump control unit |
77L |
| N121 |
Trunk lid control unit |
58L |
| N121/1 |
Tailgate control unit |
62L |
| N25/6 |
Rear seat heaters control unit |
41L |
| N25/7 |
Steering wheel heater control unit |
29L |
| N28/1 |
Trailer recognition control unit |
72L |
| N32/1 |
Driver seat control unit |
45L |
| N32/2 |
Front passenger seat control unit |
37L |
| N62/1 |
Radar sensors control unit |
49L |
| N62/2 |
Video and radar sensor system control unit |
49L |
| N80 |
Steering column module control unit |
33L |
| N99/10 |
Right front illuminated door sill molding voltage converter |
66K |
| N99/9 |
Left front illuminated door sill molding voltage converter |
65K |
| U1028 |
Valid for engine 157 |
75G |
| U240 |
Valid for all except ECO start/stop function |
1G |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
1G |
| U57 |
Valid for model 218.9 |
60G |
| U58 |
Valid for model 218.3 |
56G |
| U715 |
Valid for illuminated door sills |
64G |
| U880 |
Valid for diesel engine 642 |
7H |
| W6 |
Left rear wheel well ground point |
14H |
| W6 |
Left rear wheel well ground point |
16H |
| W6 |
Left rear wheel well ground point |
23H |
| W7 |
Right rear wheel well ground point |
8H |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
34J |
| X25/2 |
Engine compartment/interior electrical connector |
81H |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
19L |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
26L |
| X52 |
Trailer hitch electrical connector |
68J |
| X58 |
Trailer socket |
68L |
| X8/45 |
Left vehicle interior and trunk lid/liftgate electrical connector |
61J |
| Z211z5 |
Circuit 30 power supply connector sleeve |
65H |
| Z7/40z4 |
Tml. 30 connector sleeve |
83H |
