Air Spring: Notes

WARNING: This page is about a different car, the 2010 Lincoln Town Car. However, it is still accessible from the selected car via links, so may be relevant.
Special Tools

Illustration Tool Name Tool Number
GF0000049Courtesy of FORD MOTOR CO.
Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Fig 1: Exploded View Of Air Spring With Torque Specifications
GF0013908Courtesy of FORD MOTOR CO.
Item Part Number Description
1 5A9665560 Air spring
2 5A966 Air spring retainer
3 5A897 Air tube
4 14A435 Air spring solenoid electrical connector (part of wiring harness 14A435)
