Brush Check

  1. Check the brush for roughness of the surface that contacts the commutator and check the brush length. Replace the brush holder if this measurement exceeds the limit.
    • Minimum limit: 7.0 mm (0.28 inch)
  2. In the case contacting surface has been corrected or the brush has been replaced, correct the contacting surface by winding sandpaper around the commutator.
    Fig 1: Checking Brush For Roughness
    G02417500Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
