DTC C1505: Steering angle sensor (detected by ASC side); DTC C1506: Steering angle sensor error (detected by itself): Notes

Fig 1: Steering Wheel Sensor Communication Circuit Diagram (Eclipse)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Fig 2: Steering Wheel Sensor Communication Circuit Diagram - Eclipse Spyder (1 Of 2)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Fig 3: Steering Wheel Sensor Communication Circuit Diagram - Eclipse Spyder (2 Of 2)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines.

CAUTION: The steering wheel sensor-related DTC may be set when DTC C1506 is set. Diagnose the steering wheel sensor first when the steering wheel sensor-related DTC is set.
