Pre-removal operation
|
Post-installation operation
- Fuel Rail and Fuel Injector Assembly Installation (Refer to INJECTOR
).
- Throttle Body Installation (Refer to THROTTLE BODY
).
- Air Cleaner Assembly Installation (Refer to AIR CLEANER
).
- Charge air cooler Intake Air Hose A Installation (Refer to CHARGE AIR COOLER
)
- Engine Cover Installation (Refer to ENGINE COVER
).
|
