Chrysler Corp.

Turn key to "LOCK" position and remove key. Insert cylinder into housing far enough to contact switch actuator. Insert key, press inward and rotate cylinder. When parts align, cylinder will move inward and a spring loaded retainer will snap into place, locking cylinder into housing.

Fig 1: Typical Chrysler Ignition Switch And Lock (Fixed Column)

Courtesy of FORD MOTOR CO.
