Torque Specifications
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Steering Wheel Nut | 30 (41) |
| Bracket-To-Upper Support Bolts | 20 (27) |
| Bracket-To-Instrument Panel Stud Nuts | 20 (27) |
| Flexible Coupling Nuts | 20 (27) |
| Upper Intermediate Shaft-To-Steering Column | 40 (54) |
| Intermediate Shaft-To-Steering Shaft Bolt | 35 (47) |
| Lower Intermediate Shaft-To-Steering Gear Box | 35 (47) |
| INCH Lbs (N.m) | |
| Ignition Switch Screws | 35 (4) |
| Dimmer Switch Screws | 35 (4) |
| Multifunction Switch Screws | 27 (3.1) |
| Multifunction Switch Arm Screws | 19 (2.2) |
| Lock Cylinder Screws | 22 (2.5) |
