Install

Heater And A/C Evaporator Module:

Heater & Evaporator Module:

Heater And Evaporator Module Legend (2 Of 2):

INSTALL OR CONNECT
1. Heater core.
2. Heater core cover.
3. Floor air outlet duct and hoses to duct.
4. Right and left sound insulators.
5. Hoist vehicle.
6. Drain tube.
7. Heater hose to core.
8. Lower vehicle.
9. Fill cooling system.
