Cruise Control Release Switch & Brake Switch

Depress brake pedal and insert cruise control release switch and brake switch into proper pedal receptacle until retainer on switch is fully seated. See Figure . Slowly pull brake pedal back to its fully retracted position (requires 50 lbs. of force) until click sounds are no longer heard. Switches will move within switch retainers to proper adjustment.
Ensure switch contacts are open at 1.0" (25.4 mm) or less of pedal travel. Contacts should be open at same time or before onset of braking. Cruise control system should disengage at about 1.0" (25.4 mm) of pedal travel. Check brakelights for proper operation.
