Axle Shaft Assembly
article: docid= 1344324Wheel Drive Shafts Disassembled Views
Rear Drive Shaft
1 - Rear Drive Shaft Assembly
2 - Spindle Bolt Retaining Plate
3 - Bolt
4 - Small Boot Clamp
5 - Constant Velocity Joint Boot
6 - Large Boot Clamp
7 - Dust Shield
8 - Constant Velocity Joint
9 - Retainer Clip
10 - Dust Cap
